| Website Product Description | M2.0 × L Button Head Screw A2 Stainless Steel 7380-2 Natural Finish | M2.5 × L Button Head Screw A2 Stainless Steel 7380-2 Natural Finish |
|---|---|---|
| SKU | MF-BH-M2.0XL-A2-7380-2-NAT | MF-BH-M2.5XL-A2-7380-2-NAT |
| Product Family | HEX Socket Screw | HEX Socket Screw |
| Thread Diameter | M2.0 | M2.5 |
| Thread Pitch | 0.4 | 0.45 |
| Length | L | L |
| Material | Stainless Steel | Stainless Steel |
| Material Grade | A2 | A2 |
| Property Class | A2-70 | A2-70 |
| Standard | DIN7380-2 | DIN7380-2 |
| Equivalent Standard | N/A | N/A |
| Drive | Hex socket | Hex socket |
| Drive Size | T6 | T8 |
| Head Diameter | 4 | 5.5 |
| Head Height | 1.23 | 1.43 |
| Thread Length | Full | Full |
| Finish | Natural | Natural |
| Thread Tolerance | 6g | 6g |
| RoHS | Yes | Yes |
| REACH | Yes | Yes |
| CAD | Yes | Yes |
| Drawing |
DIN7380-2
Product Overview：DIN7380-2
Product Sizes：M2.0,M2.5
Product Lengths：L
Product Materials：Stainless steel
Thread Diameter：M2.0,M2.5
Thread Pitch：0.4,0.45
Product Drawing：⬇️ DIN7380-2 Drawing.zip
